Lighting Fixtures

Transformers kits available at 36 watt, 60 watt & 100 watt capacities.  Kits include: Transformer, Timer, Dimmer w/ Remote and 9' Quick Connect lead wire.

​

Pyramid

Installation Instructions

Flat Top

Wiring

In-Line Connector​

Recessed Stair Light

2" (Black Only)

Mounts flush to the riser and does not require a cut out for a back box.  The louvered design directs the light downward and right onto the stair tread.  Draws 1 watt.   ​

​

Designed to be mounted into the riser of a stairway to illuminate treads.  The light is set at a 35 degree angle to cast light directionally onto steps.  Draws 1 watt.   ​

​

Glow Ring Post Cap

Wiring available in 2 styles.  9' Quick Connect wire for running additional wiring from fixture to fixture.  In-Line Connector for tapping into 12 gauge perimeter wire to run lines up posts.

​

In-Line Connector

​

Quick Connect

​

Complete Full Installation Guide

Power Supply and Lighting Guide

Low Voltage Lighting

3" Post Cap

Aluminum post cap with LED glow ring light.  Lights feature 2 quick connect leads for easy wiring.  Draws 2.2 watts.    ​

​

Hooded Recessed Stair Light

Power Supply

Gallery

Remote Dimmer​

Strip Lighting​

Vertical Post Light

Solar Down Light Post Cap

Down Light Post Cap

Post Caps, Post Lights & a variety of stair lighting make this a complete line of low lighting products.  All fixtures feature 2 - 3' quick connect leads for easy wiring.

​

Solar Post cap does not require any wiring.  Aluminum post cap features LED down lights on all 4 sides, State of the Art solar collector and long lasting Lithium Ion Battery.

​

4" Post Cap

Pyramid

Recessed Stair Light

Can be used for stair lighting and/or under rail lighting.  Uses 3M adhesive backing to attach to and clean flat surface.  30" strip (2.5 watts) 55" strip (4.5 watts)

​

Strip Light

LED vertical post light fits posts 2" or wider and is great for illuminating decks and walkways.  Features 2 - 3' quick connect leads for easy wiring.  Draws 1 watt.

​

Louvered Stair Light

3-5/8" Post Cap

Louvered Light​

Flat Top

Aluminum post cap features LED down lights on all 4 sides to cast light in all directions.  Lights feature 2 quick connect leads for easy wiring.  Draws 3.5 watts.   ​

​

Vertical Post Light

Designed to be mounted into the riser of a stairway to illuminate treads.  The hooded light cast light downward onto steps with minimal light coming straight out.  Draws 1 watt.

​
